The Radio Shack Pro96 You Can Still Use Today
I've had a Pro96 Phase 12 on my desk for about eight years now. Bought it at a pawn shop for $75 with one channel that had a crackly fader. Fixed it with DeoxIT and a little patience. The thing still runs, still sounds fine, and honestly it's more capable than most people remember. Radio Shack's Pro96 line came out in the late 1980s and went through several hardware revisions over its production run. The Phase 12 is one of the later iterations and it's the one most people end up with because it's the one that survived longest in church basement studios and community theater shops. It's a 12-channel analog mixer with built-in parametric EQ on the first four channels, a stereo subgroup bus, and a decent noise floor for the price bracket it was sold in back then.
Radio Shack Pro96 Phase 12 Console Audio Workhorses That Never Go Out Of Style
Here's how I get one working if you find one at a garage sale or online, most of which will need some attention before they're road-ready. Step one: visual inspection. Open the top cover and look at the main power supply capacitors. The Pro96 uses standard radial electrolytics in the power supply section — usually 1000µF to 2200µF at 25V. By year twenty-five or so, at least one of them is probably swollen or leaking. If you see brown crust around the base of any capacitor, that's your problem. Replace all of them while you're in there, not just the obvious ones. A full set costs about twelve dollars at Digi-Key and takes twenty minutes with a basic soldering iron. Step two: faders and switches. This is where most Pro96s fail. The faders are generic B&O-derived carbon strip units. They wear out. Spray DeoxIT F5 into each fader slot, work it up and down about fifty times, and see if the crackling stops. If it doesn't, the fader needs replacement. I've found surplus Newoldstock faders on eBay occasionally for around $8 each, but more often I just order a box of generic mixer faders and adapt them. The channel strip layout is consistent enough across Phase 12 units that cross-referencing part numbers is straightforward.
Step three: the parametric EQ section. The four-channel parametric section is the Pro96's standout feature. It's a genuine sweepable mid with variable Q, which was unusual at this price point. Sometimes the sweep potentiometer develops intermittent contact. If the mid frequency jumps around when you touch it, clean the pot with contact cleaner and work it through its full range. Don't force it if it's stiff — these pots get brittle with age. If cleaning doesn't help, the pot is wearing out and needs replacement with a linear audio taper of the same resistance value, which is typically 100K for the sweep and 50K for the Q control. Step four: input transformers and preamp gain. The mic preamps on the Phase 12 use discrete transistor stages followed by an op-amp output buffer. Some units develop a faint hum that tracks with channel volume. Nine times out of ten this is a cold solder joint on the ground return path of the channel PCB. Resolder all the ground connections on each channel board, especially the star ground point near the input jack. I also like to check the input coupling capacitors — they're typically 0.1µF polypropylene and can go dry over decades, introducing a subtle high-frequency roll-off that makes the mixer sound muffled compared to a fresh unit. Once you've done that, the console should be functional. A Phase 12 Pro96 will give you clean gain up to about +20dBu on the line outputs, which is more than enough for most PA systems and recording interfaces. The built-in compression on channels five and six is decent for vocals but shouldn't be the reason you buy one — it's serviceable at best and inconsistent between units.
Get the Full Details
Here's something most guides don't mention: the Pro96 Phase 12 has a known issue where the +4dBu / -10dBu output level switch can develop high resistance over time, causing a significant level drop on whichever setting you've selected. I ran into this on my own unit about three years in. The symptom is subtle — one output level setting gives you normal volume and the other is roughly 8dB quieter, and sometimes it's intermittent. The fix is desoldering the switch and cleaning the contacts thoroughly with contact cleaner, or replacing the switch entirely with a higher-quality toggle if you can find one. I ended up permanently soldering it to the +4dBu position because that's what I needed for my interface, but I kept the switch in place in case I ever needed the consumer level for a direct recording feed. The build quality on these consoles was solid for the era. Steel chassis, decent transformers, and components that were spec'd conservatively enough that they rarely fail catastrophically. When they break, it's usually wear items — faders, pots, capacitors — not design flaws. That's why they're still useful twenty-plus years later. If you're using one for live sound, it handles guitar amplifiers and vocal mics without coloring the signal aggressively. The EQ curves are fairly musical — the low shelf rolls off smoothly around 80Hz and the high shelf adds air without becoming harsh. For a home studio recording application, the direct outputs are clean enough to run into an audio interface, though you'll want to keep the output gain below clipping to maintain the noise advantage these mixers have when they're in good condition.
The main limitation is channel count. Twelve inputs isn't a lot if you're tracking a full band. But for a duo, a solo singer, or a small podcast setup with two mics and some line sources, it's plenty. And the cost of ownership is essentially zero after the initial refurbishment, which comes to maybe $50 in parts if you replace everything proactively. I've seen other people restore these and sell them for $200 to $400 online, which feels generous given how common they are. But the market exists because there's genuine demand for affordable, serviceable analog mixers, and the Pro96 Phase 12 fills that slot better than almost anything else in its price range.
